The performance of small double roll mill in laboratory is as follows:

* the steel roller is driven by brand motor, and the speed control is stable.

* hard chromium plating on steel roller surface and polishing with mirror surface.

* automatic stop protection device for protective cover.

* the scope of work can be adjusted arbitrarily.

* electric heating / oil heating can be selected according to process requirements.

* dual roll spacing adjustable manually.

The application scope of small double roll mill in laboratory is as follows:

* formulation of rubber and plastics

* mixing and plasticizing of rubber and plastics

* mixing and vulcanization of rubber

* preparation of rubber and plastic sheets

* optimization and control of process parameters for rubber processing

Technical parameters of Technical Parameters / laboratory small double roll open mill:

Model / model HTR-300

Sheets thickness Range / sheet thickness range 0.2-2mm

Roll Surface Width / roll width 300mm

Heating Method / heating mode Electrical / Oil heating

Max. Temp. / maximum temperature 300 C

Temp. Control Accuracy / temperature control accuracy + 2 C

Motor Power / main motor power 3.75kw

Weight / weight 250kg

Dimendion / outline size L * W x H 860 * 700 * 1520mm
